Durodyne








Spare Parts

For a full list of Duro Dyne Spare Parts, please reference the PDF to the right.

PINSPOTTER REPLACEMENT PLATES & TIPS

Upper and lower weld plates need to be replaced as basic maintenance of your bulk feed pinspotter machines. Replacing the plates at the right time will prevent you from having to replace the whole tip. See our Technical Bulletins #12 and #13 for replacement instructions.

Image 2 Machinery Consumables Lit Sheet >
Lower Replacement Plate Instruction Sheet>
Upper Replacement Plate Instruction Sheet>

















FOOT PEDAL

The cast aluminum foot pedal from Duro Dyne comes standard with certain models of machinery to free up the operators hands for easier material handling. It is a light, durable, cast aluminum foot pedal and features a large opening to accommodate todays steel/composite toe boots.

It can accept a maximum voltage of 250VAC and can be used universally on all our machines that accommodate a foot pedal option such as the RH series pinspotters, FG series pinspotters and Rod Lock Insertion machine.

Image 2 Foot Pedal Lit Sheet >























BALL TRANSFER

Roller feed tables enable work to be easily positioned by the operator; in many cases with just one hand. Productivity is increased and worker fatigue is minimized.

Image 2 Ball Transfer Lit Sheet >













LIFT KIT

An optional machinery lift kit is also available for a custom ergonomic work space. Multi-Height Pinspotter Lift Kit will allow for height increase of 4’’ or 6’’.

Image 2

































Image 2
Spare Parts List >



Image 2
Insulation Fastening Product Catalog >


See Our Video
